You can always contact us for any return questions at sales@printheadandpart.com.The high-density structure of Konica Minolta KM1024i SHE 6PL Printheadfeaturing 4 lines of 256 nozzles aligned with high precision enhances positioning accuracy to realize high-definition print quality. The Konica Minolta KM1024i SHE printhead offers a Maximum Drive Frequency of 60kHz, approximately 3 Times greater than that of the KM1024 Series, which makes it the ideal inkjet printhead for development of single-pass system inkjet printers capable of high-speed printing.
Environmentally-considerate Approved Green Product
Konica Minolta KM1024i SHE 6PL Printhead incorporates only approximately one-third of the petroleum-derived materials and toxic chemicals used in the current KM1024 Series. In addition, the nozzle unit surface area is the same as that of the KM1024 Series.
Specifications
• Technology: Piezo Drop-On-Demand
• Native Resolution: 360 dpi
• Cal. Droplet Size: 6 pl
• Max. Drops in Greyscale: 8 drops
• Tot. Amount of Nozzles: 1024 (256 nozzles per line)
• Print Width: 72 mm
• Typical Firing Frequency: 50 kHz
• Max Firing Frequency: 60 kHz
• Ink Compatibility: UV Inks
• Heater: integrated
• Dimensions: W131mm x D18mm x H94mm
• Weight: Approx. 150g
Used on the machine:
Agfa:
Anapurna 100,
Anapurna H2500i LED,
Anapurna M2050i,
Anapurna M2500i,
Anapurna M3200i
Allwin:
S320UV,
S500UV,
UVT 2030,
UVT 2512,
UVT+ 2030,
UVT+ 2512
Docan: H1000
Flora:
HJ 5000UV
Human Digital Technology:
M-JET
IIJ: ColourPrint-72
JHF Vista:
R3300,
R6000,
V300UV,
V500UV
Optimum Digital:
KR Hybrid UV
Skyjet:
FT2512i,
FT3020i
